High-performing, extremely narrow, can be shortened as needed – “Advantix Vario” from Viega has impressed with its outstanding design and high flexibility since its market introduction. The successful shower channel is now supplemented by a version for wall installation. This is also fully variable in length and can be integrated very subtly into the tiling thanks to the drainage gap height of just two centimetres. “Advantix Vario wall drain” has already been awarded with the “Design plus powered by ISH” label.
Flush-to-floor showers are gaining in design strength due to the integrated tiling. Nevertheless, tile cutting is still often needed for technical reasons. These “inclines” are completely obsolete for the “Advantix Vario wall drain”: It drains over the entire length and manages with an incline of just one to two percent. Even large tiles can be fitted here without any problems.
Well-designed solutions
In terms of style, the “Advantix Vario wall drain” scores points with its consistent, puristic design which allows particularly subtle integration into the tiled floors with a metal grate of just four millimetres in width and colour-coordinated cover caps. The grate and cover caps are available in matt and gloss stainless steel as well as in black and white.
The new shower channel for wall installation can be combined with all ceramic coverings up to a thickness of 2.8 centimetres.
Perfect interior workings
The “Advantix Vario wall drain” is a drain which disappears subtly into any wall. The low installation depth of just 2.5 centimetres allows various opportunities to install in lightweight construction wall, a pre-wall installation or even in front of a solid wall. The shower channel itself, consisting of a base plate and narrow, attractive stainless steel grate can be shortened with millimetre-precision to fit an area of between 120 and 30 centimetres. This means it can be installed without any problems, even in small bathrooms or precisely into a shower corner. Its drainage capacity is between 0.6 and 0.75 litres per second depending on the installation.
Variations for bathroom renovation
For bathroom renovations, where there are normally only very narrow installation heights, the manufacturer offers a special design with a particularly flat drain (70 millimetres instead of 90 millimetres on the standard model). But despite the low height, a sufficient water seal head is preserved to protect against odours.
Easy cleaning
The “Advantix Vario wall drain” is optimised in terms of flow and designed to be self-cleaning as a result. In addition, the base plate has smooth walls so that no hair, etc. can get caught. All you need is a cloth to clean the channel hygienically.
